Device Details

Device Overview

Name/Version: MIKADO Midi InstruRack chain selector 2017 1.0
Author: spiralune
Description: Based on: ChaineActivatorMidi by morganjenks
http://www.maxforlive.com/library/device/3895/chainactivatormidi

audio version here
http://www.maxforlive.com/library/device/4572
------------------------


ATTENTION READ THIS FIRST

""RAck at the rigth of this patch is auto mapped to Chain Selector and no need assigned anything ""

""each chain selector need diagonaly assigned=0-127""

""Clic REFRESH auto Num Number of Chain in the Rack""
--------------------------------------------

this patch is use to make rack instruments or FX

to work as pseudo Program change .. with 128 preset

who eatch chaine selector is one preset ..

2 assignable up down Button preset chain selector
( preset up down .. loop end auto return to first)
1 assignable chain selector NumBox to rotary CC

chain can recall with a same number at the rigth off the CLIP Name ((bass funky 18 = recall chain 18)

up down directely recall adjacent preset just recalled
((17-19))

Save CPU Button =Other Chain FX OFF
auto desactivate all other plug or instruments in another Chain.
----------------------------------------------------------------------------
so eatch Rigth Number in the Named on eatch Clip on eatch Track on the scène recall All there specifics Preset Like a Groove box ..
Live Scène= Pattern
Number in the Clip name = Preset of that Track
each clip has its preset .. cool
and fun for Live with 8 Track ...
Because eatch track can have 0-127= 128 vst instruments at presets if you want
CPU friendly with Button= OtherFx OFF =AUTO desactivate All Plug to another Chain

--------------------------------------
iam use it to recall instrument/vST chain preset

add assignable midi -- inc / dec -- with loop the last chain to the first chain

number of chain auto detect when clic refresh ( chain number = 0 to 127 )

Number at the end of clip name recall this chain
exp1: midi clip name : Bass fret cool 14

Button inc / dec direct recall good next / preview chain = so 13 or 15

exp2: 33 Bass Lead 23 = call chain 23

(( Number must be at Right !!! Because ??
Ableton auto Name new Clip Recorded and
set number at LEFT
and need avoid new rec midi clip to interact with the chain )) cool
-------------------------------

button " OtherChainFX-OFF "
desactivate all plug to all other chain

you can select " OtherChainFX-ON"

if you pc have good proc and ram
and you need extrem reactivity at extra low latency
without draoput and click when need to change quickly preset , Even while continu to playing
-------------------------------------

Add ,, Send ALL Note OFF and Pedal Sustain OFF
at change ((prevent note blocked))
---------------------------------------------------------------------

To avoid reconfiguring your midi controller button

Button assign to midi note or midi CC ((no noteoff))

if assigned ""inc /dec "" from controller::

-- need double clic to work correctly
-- or clic once , jump two chain

try another .. button position
it's save with ableton project


Device Details

Downloads: 544
Tags utility
Live Version Used: 9.6.2
Max Version Used: 6.10
Date Added: Apr 01 2017 02:47:59
Date Last Updated: Feb 21 2018 13:49:33
Average Rating -n/a-
Rate this device: (must be logged in to rate devices login)
Device Type: midi_device
URL (optional):
License (more info): AttributionNonCommercial

Device Files

Device File: MIKADO Midi instru Rack chain selector 2017 .amxd



Comments

I'd like to know if I could create another mode where the m4l device autodetects the number of plugins, then update the chain automatically (one more plugin = one more chain) and then handle automatic activation/desactivation when a chain is selected (instrument is activated on the selected chain).
Thanks for help

sorry I didn't realized this was already implemented...

Great thing! I was waiting for this. But one question: is there a possibility to use you plug with an AUDIO effect rack? I have one instrument track and i use multitimbral -- i want to activate your chain selection on my kick, snare, hh etc which own to some audio tracks... . Thanks for your answer.

hi Barnes

Thank to your interest

check this news version

http://maxforlive.com/library/device/4572/mikado-audio-fx-rack-chain-selector-2018

------

remenber Chain selector value can olso recall
by CLYPHX SNAP ACTION
instead of Rigth Clip Name Number

http://beatwise.proboards.com/thread/992/current-version-clyphx-live-9
